Fume Extractor Arms

Our Welding Fume Extraction Arms are built to provide effective source capture in a variety of configurations:

Hanging Arms

Hanging Fume Extraction Arms are our most popular style! They easily mount to ceilings, walls, or posts and provide 2x the suction distance when compared to competitors.
Explore Hanging Arms
Standing Arms

Standing Fume Extraction Arms mount to a table-top or work-bench. They provide the best extraction for table-top projects, where a wall, ceiling, or post mount is not possible.
Explore Standing Arms

FAQ

Our fume extraction arms are designed to capture and control welding fumes, smoke, and other airborne contaminants at the source, protecting the safety of your machine operators.

Our fume extraction arms use a simple yet effective process:
1. The flexible arm is positioned near the source of fumes or smoke.
2. Our 360° rotating hood captures contaminated air.
3. A blower system pulls the air through the arm.
4. The air passes through a filtration system, removing harmful particles.
5. Clean air is then returned to the facility or exhausted outside.

Our arms are self-supporting and easily adjustable, ensuring continuous fume capture without restricting the operator's movement.

With 2x the suction distance of competitors, Fume Xtractors arms efficiently control air contaminants while using less energy, providing better air quality and lower operating costs for your facility.

Fume Xtractors fume arms are designed for the following welding applications:
• MIG/GMAW
• TIG/GTAW
• Flux Core/FCAW
• Stick/SMAW

Designed for all shifts: Stick, Flux Core, MIG, or TIG welding

We offer a range of sizes, with diameters from 3-8 inches and lengths from 5-feet to 14-feet. Our experts can help you select the perfect size for your specific application and workspace.

Our arms feature solid metal construction for durability. We also offer stainless steel options upon request.

Our arms provide airflow ranging from 230-1200 CFM, depending on the model, ensuring effective fume capture for your needs.

Our hood diameters range from 13" for 6" diameter arms to 14" for 8" diameter arms, providing excellent coverage for fume capture.

Our extraction arms provide 2x the suction distance when compared to competitors, thanks to our flanged hood design which reduces false air intake.

We offer various mounting options including ceiling, wall, post, and table-top mounts. Our hanging arms are particularly versatile, easily mounting to ceilings, walls, or posts.

Our fume extraction arms offer greater flexibility, allowing you to position them directly above the source. This targeted approach is often more effective than stationary fume hoods.

Warranty

It is our goal to ensure that customers are 100% satisfied with their purchases, that’s why our products are designed to deliver high-quality standards and long-lasting performance.

As the original purchaser, we guarantee that your Fume Xtractors extraction system will remain free from defects in material within two years of its original purchase. If such defects appear under normal usage, we will repair or replace your product at no cost to you.

Please refer to the Owners Manual for more information about our Two Year Limited Warranty.
